CONTROLLINO MINI

605 in stock

The MINI is the smallest child in our CONTROLLINO family. But no worries – it’s still a big boy when it comes to the number of inputs and outputs (8 each). The incredible size to I/O ratio makes the MINI one of the most compact and versatile PLCs on the market.
Pinheader protection caps included!

_0019_MINI

119.00 excl VAT

605 in stock

SKU 100.000.00 Category:

Description

The MINI is the smallest child in our CONTROLLINO family. But no worries – it’s still a big boy when it comes to the number of inputs and outputs (8 each). The incredible size to I/O ratio makes the MINI one of the most compact and versatile PLCs on the market.

Features MINI
5V Pin Headers Yes
Analog/Digital Inputs 6 (2x only Analog)
Only Digital Inputs 2
Analog 0-10V Inputs no
Interrupt Inputs 2
Digital 2A Outputs 8 (3 PWM)
Analog 0-10V Outputs no
Relay Outputs 6 (parallel to Digital Outputs)
Serial TTL Interface 1
I²C Interface 1
SPI Interface 1
RS485 Interface no
RTC 1
Ethernet Interface no
Stepper Driver Output no

Additional information

Weight 0.2 kg
